IEC 71/B14 TENV 110ZY PM DC Motor
① Characteristics
IEC 71/B14 110ZY DC BRUSH MOTOR GENERAL SPECS.
· Motor OD: 110 mm
· Voltage: 12V DC, 24V DC, 48V DC, 110V DC, 300V DC
· Power: 200W ~ 1250W
· Output Speed: 500 ~ 9000RPM
· Without Gearbox
· Customized shaft & front cover available upon request (Mounting NEMA 48C, NEMA 56C, IEC61/71/80 B5/B14, NEMA 143TC/145TC, TENV, TEFC)
110ZY DC BRUSH MOTOR TYPICAL SPECS.
Model No. | Voltage | Rated Power | Rated Speed | Rated Torque | Rated Current | No Load Speed | Length |
Units | V | W | rpm | N.m | A | rpm | mm |
110ZYT24-1000 | 24 | 1000 | 7000 | 1.40 | 55.5 | 8000 | 188 |
110ZYT24-600 | 24 | 600 | 3000 | 1.95 | 33.0 | 3700 | 228 |
110ZYT220-700 | 220 | 700 | 3000 | 2.25 | 4.0 | 3500 | 218 |
